SKU: LEGACY-00026Brand: HairiseCategory: Conveyor System
Suitable for goods:
Product specifications
Features:
• Suitable for goods:Liquid containers like: bottles, glass or pet for drinks, personal care or pcbmsmaceutical. Primary packing like: cartons, candy bars, personal care and pcbmsmaceuticalsDetailsBelt width range: 100 - 140 mm | 4-5.5”Multi belts: patented up/down spiral with ONE-beltLoad range: up to 50 kg/m |34 lb/ftSpeed range: up to 60 m/min | 200 fpmBelt length: commonly per drive system 120 m | 400 ft
Suitable for goods:
Details
The Hairise Series is designed for time delay or medium pressure accumulation. It is specially
designed to save space. Its ultra-compact design offers up to an astonishing 51 m/m2 (15.5 ft/ft2)
conveyor metres per square metre footprint. Based on a Spiral conveyor with one belt, running both up
and down in a concentric arrangement. When installed in its time delay configuration, it offers the most
time delay per footprint possible. It is also compact and simple, and able to handle almost all primary
packed products as well as liquid containers in single file. When used as a medium pressure accumulator,
the smooth belt surface slips under the items.
Suitable for goods:
Liquid containers like: bottles, glass or pet for drinks, personal care or pcbmsmaceutical. Primary packing like:
cartons, candy bars, personal care and pcbmsmaceuticals
Details:
Belt width range: 100 - 140 mm | 4-5.5”
Multi belts: patented up/down spiral with ONE-belt
Load range: up to 50 kg/m |34 lb/ft
Speed range: up to 60 m/min | 200 fpm
Belt length: commonly per drive system 120 m | 400 ft
